Mastercool Mini-Fold Compact 2-way Aluminum Manifold 94103
Mastercool Mini-Fold Compact 2-way Aluminum Manifold 94103 in the case
Mastercool Mini-Fold Compact 2-way Aluminum Manifold 94103 Flyer
Mastercool Mini-Fold Compact 2-way Aluminum Manifold 94103 Flyer
Mastercool Mini-Fold Compact 2-way Aluminum Manifold 94103
  • SKU: 94103

Mastercool Mini-Fold Compact 2-way Aluminum Manifold 94103

$384.80
GST included.
    DESCRIPTION

    94103 Mastercool Mini-Fold Compact 2-way Aluminum Manifold

    DOWNLOAD BROCHURE

    DOWNLOAD INSTRUCTIONS

    Mastercool’s NEW Black Series Compact Two-Way Digital Manifold Gauge Set

    • Effortlessly performs pressure and temperature calculations and displays them on a large blue backlit LCD display
    • Constructed of the finest materials and machined with precision to the highest quality standards this compact manifold provides automatic shut-off, units conversion, over-range alarm, max and min values and refrigerants selection providing for a powerful tool for the hard-working technician



    FEATURES AND CAPABILITIES

    • Compact Footprint: Compact Black anodized aluminum block with matte chrome fittings offer an extremely portable solution to fit the needs of every busy technician
    • 91 Refrigerants: Easily perform pressure/temperature calculations for up to 91 different refrigerants including R134a, R410a and R22 refrigerants
    • Unit Conversion: Between MPa, kPa, bar, psi, kg/cm2, inHg
    • Large LCD Display: The large 4-digit “Blue” backlit LCD display provides vibrant readings in even the darkest of environments
    • Displays alarm indication when over range, Celsius or Fahrenheit designation and low battery warning directly on the LCD screen
    • Large chrome-rimmed sight glass for quick visual refrigerant checks
    • Front-mounted hose holders allows for precise calculations in the palm of your hands
    • 1/4” SAE flare fittings
    • Rubber gauge guards
    • Easy-to-grip knobs
    • 1-Year warranty


    WHAT'S INCLUDED

    • 1 x 94103 Black Series Mini-Fold Compact Manifold with gauges only (packaged in a cardboard box)



    SPECIFICATIONS

    Low Pressure Range -14.5 – 500 psi (-0.1 – 3.4 MPa)
    High Pressure Range -14.5 – 800 psi (-0.1 – 5.5 MPa)
    Resolution 0.5 psi
    Accuracy +/-0.5% FS
    Measurement Units MPA, kPa, bar, psi, kg/cm2, inHg
    Temperature Unit ˚C/˚F
    Over Range Alarm Display -OL-
    Operating Temperature -10˚C to 60˚C
    Battery CR2450
    Battery Life Approximately 6 months
    Sampling Rate 1 second
    Low Battery Indication icon on LCD
    Display 30 mm x 17 mm LCD
    Blue Backlight Auto-off after 6 seconds
    Included Refrigerants R11, R113, R114, R115, R116, R12, R123, R1234yf, R1234ze, R124, R125, R13, R134a, R14, R141B, R142B, R413A, R152A, R161, R170, R21, R218, R22, R23, R290, R32, R401A, R401B, R401C, R402A, R402B, R403A, R403B, R404A, R406A, R407A, R407B, R407C, R407D, R407E, R407F, R408A, R409A, R409B, R41, R410A, R410B, R412A, R413A, R414A, R414B, R415B, R416A, R417A, R419A, R420A, R421A, R421B, R422A, R422B, R422C, R422D, R423A, R427A, R437A, R441A, R442A, R443A, R444A, R448A, R449A, R449B, R450A, R452A, R455A, R50, R500, R502, R503, R504, R507A, R508A, R508B, R509A, R513A, R600, R600a, R601, R601a, R740, R744
