Fieldpiece Refrigerant Recovery Kit RRK

A great kit to get the job done.

WHAT'S INCLUDED

1 x Fieldpiece 6 CFM Two Stage R32 Vacuum Pump VP67INT

• VP67INT Vacuum Pump
• 2 x 8oz RunQuick Oil Containers (Filled)
• Operator’s Manual

1 x Fieldpiece 2-Valve Wireless Refrigerant Manifold SM380vINT

• SM380vINT
• 2 x TC24 Wired Type-K Pipe Clamp thermocouple
• 1 x ATA1 Type-K Bead Thermocouple with clip
• 1 x ANC11 Padded Drawstring Case

1 x Fieldpiece Digital Refrigerant Recovery Machine MR45INT

• MR45INT Refrigerant Recovery Machine
• 10 Extra Mesh Screens for Input Port
• 3 Extra O-ring for Input Port
• Operator’s Manual

FEATURES AND CAPABILITIES

Fieldpiece High-Efficiency Vacuum Pump VP67INT

• 6 CFM (170 l/m) with Variable Speed DC motor
• 15 Micron ultimate Vacuum
• 1/2 HP AC motor
• Backlit oil reservoir to view condition of oil and system
• RunQuick™ Oil Change System offers on-the-fly oil change in seconds
• Extra oil bottle storage
• Includes 2 x 237ml Oil filled RunQuick Oil Cartridges
• Water-resistant to withstand direct rain
• Port Sizes: (1) 1/4”, (2) 3/8”, (1) 1/2” for easy hose connections

• Sturdy base stays upright

• Small footprint – 1,346 cubic inches

• Quarter-turn gas ballast with LED indicator

• Convenient, removable cord storage
• Suitable for A2L class refrigerants
  • R32, R1234YF, R1234ZE, R512A, 419B, 439A and other

Fieldpiece 2-Valve Wireless Refrigerant Manifold SM380vINT

Data Logging

• Stores up to 9 jobs internally
• Easy download via USB port
• Displays % free storage space before logging begins
• Logs up to 7 days (168 continuous hours)

Tightness Test built in feature

• Check for leaks after repairs or installations
• View pressure differential over time
• Timer tracks duration of test
• Temperature compensated with SL temp to avoid false positives

Customisable Menu

• Adjust auto power off duration
• Adjust back light duration
• Set high and low vacuum alarms
• Select each unit of measurement individually

Receives Wireless Measurements

Add Job Link Tools to your arsenal and get live readings directly on the SMAN manifold screen from the Job Link Psychrometers (JL3RH), Job Link Pipe Clamps (JL3PC), and SRS3 Refrigerant Scale.

Place pipe clamps in the perfect location. Monitor and record live refrigerant usage for precise recovery, charging, and documentation. View live air measurements and calculations while making adjustments.

Increase Professionalism with Job Link® System App
Streamline and simplify your call even further with the Job Link System App. See your measurements up to 100 metres away on your mobile device. Document your work and provide professional reports, including refrigerant weight usage, by simply connecting to the Job Link System app. Helps to reduce call-backs and increase profits.

• View measurements on SMAN and/or in Job Link App
• Monitor and record refrigerant weight
• Direct 100 mtr wireless range (no transmitter needed)

Fieldpiece Digital Refrigerant Recovery Machine MR45INT

• Dual cylinder compressor with long life and low friction with ceramic lined cylinders
• Auto Shut Off when -10 Kpa reached
• Protected from voltage drop (runs as low as 190 VAC)
• Single dial self purge
• Twice the RPMs (3,000) and twice the horsepower (1HP - 0.745kW) with DC Motor
• Extra large condenser cools faster, especially on hot days
• Light Weight at only 10 Kgs
• Water & Rain resistant
• Easy access ports
• Easy hose connections and built in power cord storage
• Large backlit display with status messages
• UL Verified to Section 608 of EPA Clean Air Act
• UL Verified to AHRI Standard 740
• Suitable for use with A2L Class Refrigerants [ R32, R1234YF ... ]
• Also can be used for transferring SF6 [sulfur hexafluoride] a non-flammable gas used in electrical components.

This full-featured unit has onboard system monitoring that adjusts motor performance to handle liquid and run twice as fast on vapour. The MR45 can also step up low voltage at the supply input to deliver full power to the motor where high voltage drop is a problem. This protects your recovery unit and allows you to get on with the job regardless of power issues.

The Fieldpiece MR45INT is equipped with a powerful 1HP motor and oversized condenser, this recovery unit performs flawlessly on those longer and hotter jobs in the peak of the busy Summer season.

This Fieldpiece Recovery Unit has an easy-to-read display, is lightweight (10Kgs), comes with straight hose connection ports, and a single dial makes this machine user-friendly while being tough enough for everyday use. Its small footprint means it takes up less valuable room in your service vehicle as well.

WARRANTY

1 Year from Date of Purchase (​excludes Consumables such as Filters, Gaskets, Leads, Batteries, Fuses, Sensors, Case etc)
