Nu-Calgon Clean Guard Mini-Split Cleaning Bag XL 4150-02

4150-02 Nu-Calgon Clean Guard Mini-Split Cleaning Bag

Designed for cleaning indoor coils using Nu-Calgon coil cleaners.

• The Clean Guard CC uses a 10-foot drain line.
• 360° coverage prevents overspray on the wall

• Easiest install on the market – installs in seconds!
• Durable braided elastic band with wheel lock adjusts in seconds for a desired fit
• Heavy duty design
• Eight-foot drain line for Clean Guard (XL).
• Reusable
• Industrial Grade Elastic Collar adjusts automatically to mini-splits between 18,000 to 36,000 BTU

Clean Guard and Clean Guard XL are reusable maintenance bags designed for HVAC contractors to clean wall-mounted mini-split units using Nu-Calgon cleaners and disinfectants. Ideal for servicing indoor coils and blowers, these bags feature a durable braided elastic band with a wheel lock for quick and easy installation around the unit—taking just seconds to set up. Offering 360-degree protection against overspray, each bag includes an integrated 8-foot drain line and is built for repeated use. After cleaning, simply rinse, dry, and store the bag in a standard 20L bucket (used to collect the cleaning solution during service). Any common 20L plastic bucket is compatible.

DIRECTIONS

This product must be used in accordance to the following directions by HVACR professionals only.

Ensure You Have Proper Supplies Before You Start. The Clean Guard (4150-01) is sized for wall-mounted mini-split indoor coils up to 12,000 BTUs (1 ton) in size. The Clean Guard will also require the use of a readily available five-gallon bucket and the use of a suitable Nu-Calgon cleaner.

1. Disconnect power from the unit.
2. Remove the return filters and protective cover off the mini-split indoor unit.
3. Simply snap the industrial elastic collar around the indoor coil. Important: Make sure the adjustable collar fits well to create a workable seal around the unit so as not to cause damage when cleaning the coil/blower followed by a power water wash if necessary.
4. IMPORTANT: The Clean Guard does not cover exposed electronics. Please be sure to protect any electronics when cleaning with a cleaner and if pressurized water is used.
5. Position the five-gallon bucket on a stable surface, typically the floor in most cases, and position the Clean Guard funnel into the bucket.
6. During cleaning, wear protective gloves and eyewear.
7. Select a Nu-Calgon coil cleaner that is best suited for the job. For coils and blowers that need to be cleaned and disinfected, Nu-Calgon’s Evap-Fresh gallon (4166-08) with the use of a 50P Sprayer (4770-0) or Evap-Fresh No Rinse aerosol (4166-75) with the use of the Talon Flexible Wand (4776- 0) are good options. For tough duty, Tri-Pow’r HD coil cleaner may be necessary; but the use of Tri-Pow’r (at a 3:1 dilution) requires a water rinse. NOTE: Some tough applications may still require a follow-up rinse with pressurized water using a market available sprayer.
8. While cleaning, keep an eye on the five-gallon bucket to make sure cleaner/water is draining into bucket properly; resolve any kinks in the Clean Guard as necessary.
9. Recommission the mini-split system back to service.
10. Rinse, dry and store the Clean Guard inside the bucket for repeated use.
