IE-114 Upfront Strippers Combination Plier Tools
- Serrated pliers nose for pulling and looping wire
- (6) up-front, precision-ground stripping stations for solid and stranded wire
- (6) bolt/screw sizing and cutting stations
- Wire cutter
- Wire terminal and 7-8 mm automotive ignition crimp stations
- Highly visible, easy-to-read graphics
- Non-insulated cushion grips
5-IN-1 Combination Tool
- Strips: 22/20/18/16/14/12/10 AWG
- Crimps insulated and non-insulated: 22-18, 16-10 AWG; non-insulated: Auto 7 & 8 mm
- Screw cutter: 4-40 / 5-40 / 6-32 / 8-32 / 10-32 / 10-24
- Wire sizes, etc., are embossed in metal and paint-filled
- Serrated pliers nose for pulling and looping wire
- Air-pocket cushion grips
- Available in AWG, metric or combination AWG/metric models
| |
IE-110 |
IE-114 |
| Description |
Super 5-in-1 Combination |
Metric |
| Stripper Size(AWG) |
10-22 |
0.75-6.0 mm², 10-22 |
| Cutter Type |
Curved-long |
Straight |
| Crimps Insulated (AWG) |
10-22 |
1.5-6.0 mm
10-22 |
| Crimps Non-Insulated (AWG) |
10-22; 7-8mm Auto |
1.5-6.0mm, 10-22
7-8mm Auto |
| Screw Cutter |
4-40 / 5-40 / 6-32
8-32 10-32 / 10-24 |
2.5/3.0/3.5/4.0
4.5/5.0 mm
|
| Nom. Length (in.) |
8-1/4 |
8-1/4 |
WHAT'S INCLUDED
- 1 x IE-114 Upfront Stripper Combination Plier Tools
